<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:layout_width="wrap_content"
  android:layout_height="wrap_content">

  <LinearLayout
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:background="@drawable/corners_bg"
    android:paddingBottom="3dp"
    android:paddingTop="3dp"
    android:paddingLeft="15dp"
    android:paddingRight="8dp"
    android:layout_gravity="center"
    android:gravity="center"
    android:orientation="horizontal">

    <TextView
      android:id="@+id/record_time"
      android:layout_width="wrap_content"
      android:layout_height="wrap_content"
      android:text="00:00"
      android:textColor="#ffffff"
      android:textSize="10dp" />
    <View
      android:layout_width="2dp"
      android:layout_height="match_parent"
      android:layout_marginLeft="5dp"
      android:layout_marginRight="5dp"
      android:textColor="#ffffff" />
    <LinearLayout
      android:id="@+id/stop_record"
      android:layout_width="wrap_content"
      android:layout_height="wrap_content"
      android:layout_gravity="center"
      android:gravity="center"
      android:orientation="horizontal">
      <ImageView
        android:id="@+id/record_hint_button"
        android:layout_width="10dp"
        android:layout_height="10dp"
        android:layout_marginRight="5dp"
        android:background="#FF4040" />

      <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="結束"
        android:textColor="#ffffff"
        android:textSize="10dp" />
    </LinearLayout>
  </LinearLayout>
</LinearLayout>

package com.android.systemui;


import android.annotation.TargetApi;
import android.app.Service;
import android.content.Context;
import android.content.Intent;
import android.os.Binder;
import android.os.Build;
import android.os.Environment;
import android.os.Handler;
import android.os.IBinder;
import android.os.Looper;
import android.os.Message;
import android.support.annotation.RequiresApi;
import android.view.animation.AlphaAnimation;
import android.view.animation.Animation;
import android.view.animation.LinearInterpolator;


import android.graphics.PixelFormat;
import android.view.GestureDetector;
import android.view.GestureDetector.SimpleOnGestureListener;
import android.view.Gravity;
import android.view.LayoutInflater;
import android.view.MotionEvent;
import android.view.View;
import android.widget.LinearLayout;
import android.widget.TextView;
import android.view.View.OnTouchListener;
import android.view.WindowManager;
import android.view.WindowManager.LayoutParams;
import android.widget.ImageButton;
import android.widget.ImageView;
import android.widget.LinearLayout;
import android.widget.Toast;
import com.android.systemui.R;
import android.util.Log;
import java.io.File;
import java.io.IOException;

public class ScreenRecordService extends Service implements Handler.Callback {


  private final String TAG = "ScreenRecordService";
  private Handler mHandler;
  //已經錄制多少秒了
  private int mRecordSeconds = 0;
  private static final int MSG_TYPE_COUNT_DOWN = 110;

  /**
   * 定義浮動窗口布局
   */
  LinearLayout mlayout;
  TextView recordTime;
  /**
   * 懸浮窗控件
   */
  ImageView recordHintButton;
  LinearLayout stopRecord;
  /**
   * 懸浮窗的布局
   */
  WindowManager.LayoutParams wmParams;
  LayoutInflater inflater;
  /**
   * 創建浮動窗口設置布局參數的對象
   */
  WindowManager mWindowManager;


  //觸摸監聽器
  GestureDetector mGestureDetector;


  FloatingListener mFloatingListener;

  @Override
  public void onCreate() {
    super.onCreate();
   initWindow();//設置窗口的參數
   initFloating();//設置懸浮窗圖標
 }
  @Override
  public void onDestroy() {
    super.onDestroy();
    try {
      if (mlayout != null) {
        // 移除懸浮窗口
        mWindowManager.removeView(mlayout);
      }
    } catch (Exception e) {
      Log.e(TAG, "not attached to window manager");
    }
  }

  @RequiresApi(api = Build.VERSION_CODES.LOLLIPOP)
  @Override
  public boolean handleMessage(Message msg) {
    switch (msg.what) {

      case MSG_TYPE_COUNT_DOWN: {

        mRecordSeconds++;
        int minute = 0, second = 0;
        if (mRecordSeconds >= 60) {
          minute = mRecordSeconds / 60;
          second = mRecordSeconds % 60;
        } else {
          second = mRecordSeconds;
        } String timeTip = ""+minute+":"+second;
        recordTime.setText(timeTip);
      }
        break;
      }
    }
    return true;
  }

  /**
   * 初始化windowManager
   */
  private void initWindow() {
    if (mWindowManager == null) {
      mWindowManager = (WindowManager) getApplication().getSystemService(Context.WINDOW_SERVICE);
    }
    wmParams = getParams(wmParams);//設置好懸浮窗的參數
    // 懸浮窗默認顯示以左上角為起始坐標
    wmParams.gravity = Gravity.LEFT | Gravity.TOP;
    //懸浮窗的開始位置，因為設置的是從左上角開始，所以屏幕左上角是x=0;y=0
    wmParams.x = 0;
    wmParams.y = 0;
    //得到容器，通過這個inflater來獲得懸浮窗控件
    if (inflater == null) {
      inflater = LayoutInflater.from(getApplication());
    }
    // 獲取浮動窗口視圖所在布局
    if (mlayout == null) {
      mlayout = (LinearLayout) inflater.inflate(R.layout.record_screen_time_float, null);
    }
    // 添加懸浮窗的視圖
    mWindowManager.addView(mlayout, wmParams);
  }


  /**
   * 對windowManager進行設置
   *
   * @param wmParams
   * @return
   */
  public WindowManager.LayoutParams getParams(WindowManager.LayoutParams wmParams) {
    if (wmParams == null) {
      wmParams = new WindowManager.LayoutParams();
    }
    //設置window type 下面變量2002是在屏幕區域顯示，2003則可以顯示在狀態欄之上
    //wmParams.type = LayoutParams.TYPE_PHONE;
    //wmParams.type = LayoutParams.TYPE_SYSTEM_ALERT;
    wmParams.type = LayoutParams.TYPE_SYSTEM_ERROR;
    //設置圖片格式，效果為背景透明
    wmParams.format = PixelFormat.RGBA_8888;
    //設置浮動窗口不可聚焦（實現操作除浮動窗口外的其他可見窗口的操作）
    //wmParams.flags = LayoutParams.FLAG_NOT_FOCUSABLE;
    //設置可以顯示在狀態欄上
    wmParams.flags = WindowManager.LayoutParams.FLAG_NOT_FOCUSABLE | WindowManager.LayoutParams.FLAG_NOT_TOUCH_MODAL |
        WindowManager.LayoutParams.FLAG_LAYOUT_IN_SCREEN | WindowManager.LayoutParams.FLAG_LAYOUT_INSET_DECOR |
        WindowManager.LayoutParams.FLAG_WATCH_OUTSIDE_TOUCH;
    //設置懸浮窗口長寬數據
    wmParams.width = WindowManager.LayoutParams.WRAP_CONTENT;
    wmParams.height = WindowManager.LayoutParams.WRAP_CONTENT;
    return wmParams;
  }

  /**
   * 找到懸浮窗的圖標，并且設置事件
   * 設置懸浮窗的點擊、滑動事件
   */
  private void initFloating() {
    recordTime = (TextView) mlayout.findViewById(R.id.record_time);
    recordHintButton = (ImageView) mlayout.findViewById(R.id.record_hint_button);
    setFlickerAnimation(recordHintButton);
    stopRecord = (LinearLayout) mlayout.findViewById(R.id.stop_record);
    mlayout.setOnClickListener(new View.OnClickListener() {
      @Override
      public void onClick(View v) {
        Log.d(TAG, "OnClickListener");
        ScreenUtil.stopScreenRecord(ScreenRecordService.this);
      }
    });
    if (mGestureDetector == null) {
      mGestureDetector = new GestureDetector(this, new MyOnGestureListener());
    }
    if(mFloatingListener == null){
      //設置監聽器
      mFloatingListener = new FloatingListener();
    }
    mlayout.setOnTouchListener(mFloatingListener);
    stopRecord.setOnTouchListener(mFloatingListener);
  }
/×
 ×錄屏狀態顯示（閃爍效果）
 ×/
  private void setFlickerAnimation(ImageView iv_chat_head) {
    final Animation animation = new AlphaAnimation(1, 0); // Change alpha from fully visible to invisible
    animation.setDuration(500); // duration - half a second
    animation.setInterpolator(new LinearInterpolator()); // do not alter animation rate
    animation.setRepeatCount(Animation.INFINITE); // Repeat animation infinitely
    animation.setRepeatMode(Animation.REVERSE); //
    iv_chat_head.setAnimation(animation);
  }


  //開始觸控的坐標，移動時的坐標（相對于屏幕左上角的坐標）
  private int mTouchStartX, mTouchStartY, mTouchCurrentX, mTouchCurrentY;
  //開始時的坐標和結束時的坐標（相對于自身控件的坐標）
  private int mStartX, mStartY, mStopX, mStopY;
  private boolean isMove;//判斷懸浮窗是否移動


  /**
   * 懸浮窗監聽器
   */
  private class FloatingListener implements OnTouchListener {

    @Override
    public boolean onTouch(View arg0, MotionEvent event) {

      int action = event.getAction();
      switch (action) {
        case MotionEvent.ACTION_DOWN:
          isMove = false;
          mTouchStartX = (int) event.getRawX();
          mTouchStartY = (int) event.getRawY();
          mStartX = (int) event.getX();
          mStartY = (int) event.getY();
          break;
        case MotionEvent.ACTION_MOVE:
          mTouchCurrentX = (int) event.getRawX();
          mTouchCurrentY = (int) event.getRawY();
          wmParams.x += mTouchCurrentX - mTouchStartX;
          wmParams.y += mTouchCurrentY - mTouchStartY;
          if (mlayout != null) {
            mWindowManager.updateViewLayout(mlayout, wmParams);
          }
          mTouchStartX = mTouchCurrentX;
          mTouchStartY = mTouchCurrentY;
          break;
        case MotionEvent.ACTION_UP:
          mStopX = (int) event.getX();
          mStopY = (int) event.getY();
          if (Math.abs(mStartX - mStopX) >= 1 || Math.abs(mStartY - mStopY) >= 1) {
            isMove = true;
          }
          break;
      }
      return mGestureDetector.onTouchEvent(event); //此處必須返回false，否則OnClickListener獲取不到監聽
    }
  }

  /**
   * 自定義的手勢監聽類
   */
  class MyOnGestureListener extends SimpleOnGestureListener {
    @Override
    public boolean onSingleTapConfirmed(MotionEvent e) {
      if (!isMove) {
        System.out.println("onclick");
      }
      return super.onSingleTapConfirmed(e);
    }
  }

}
